Specifications
• Threaded inlet: 1" NPT or 25mm BSP
• Overall height: 14.5" (36,8 cm)
• Retracted height: 10.75" (27,3 cm)
• Ratcheting riser
• Spray arc: 360° and adjustable 40°–330°
• Main nozzle trajectory: adjustable 7°–30°
• Nozzle options: 4 Main, 2 Intermediate, 1 Inner
Performance Data - U.S.
Sprinkler Model Nozzle Set
Configuration
Main / Intermediate
#5 - Green
#6 - Gray
#7 - Black
TS90TP-02TC #8 - Red
Performance Data - Metric
Nozzle Set
Sprinkler Model
Configuration Main / Intermediate
#5 - Green
#6 - Gray
#7 - Black
TS90TP-52TC #8 - Red
Note: Toro service tool 995-99 (or 5/8" nut driver) is required for main nozzle exchange. For Intermediate nozzle
exchange and main nozzle trajectory adjustment, Toro service tool 995-105 (or 5/16" nut driver) is required.
Main Nozzle Trajectory Adjustment
The main nozzle trajectory angle is factory-set at 25°, and is adjusted
between 7°—30° by turning the Trajectory Nut through the top of
the nozzle base Turret Cover (Figure 1). Typical uses of this feature
are to increase the spray radius. Decreasing trajectory decreases the
spray radius.
NOTE: Nozzle trajectory adjustment must be made prior to
installing Turf disk.
1. Locate the small, black arrow on top of the sprinkler head.
2. Install the Trajectory Nut over black arrow so that it rests flush.
3. Place the nozzle base Turret Cover over the sprinkler head. Align
into place.
4. Using a 5/16" (995-105) nut driver, turn the Trajectory Nut
clockwise to decrease trajectory or counterclockwise to increase
trajectory. (Figure 2)
Arc Adjustment
The TS90 series sprinkler features an adjustable arc from 40° to 330°, in 5° increments, or full-circle 360° operation. All
TS90 series sprinklers are preset to half-circle (180°) arc when shipped from the factory.
The left side of the adjustable arc is fixed, and is aligned to the left watering border by turning the ratcheting riser
assembly in the sprinkler body. The right side of the arc is aligned to the right watering border by turning the nozzle
turret while compressing and holding the adjustment band in a stationary position.
NOTE: Arc adjustment must be done before sprinkler and TurfCup assembly is installed.
TS90 Series Sprinkler with TurfCup
Installation & Adjustment Guide
Stator @ 50 psi
Type
Radius (ft) GPM Radius (ft) GPM Radius (ft) GPM Radius (ft) GPM Radius (ft) GPM Radius (ft) GPM
Blue 71
Medium
Blue Medium 72
Orange Medium 71
Blue Medium 74
Stator @ 3,4 bar
Type
Radius (m) LPM
Blue Medium 21,64
Blue Medium
21,95
Orange
Medium 21,64
Blue Medium
22,56
• Radius: 71'–90' (21,64m–27,43 m) @ 25° trajectory
• Flow rate: 28.1-50.3 GPM (106–190 LPM)
• Precipitation rate: 0.56–0.60"/hr (14,2–15,2mm/hr)
• Minimum pressure: 40 psi (2,7 bar)
• Maximum pressure: 100 psi (6,9 bar)
• Recommended pressure: 50–100 psi (3,4—6,9 bar)
• Check valve elevation rating: 6' (1,8m)
• Stator/Drive: Constant velocity
@ 60 psi @ 70 psi
75 30.7 79
28.1
29.8 76 32.6 79
32.2 35.3 80
77
35.7 78 39.2 82
@ 4,1 bar
@ 4,8 bar
Radius (m) LPM Radius (m) LPM
106
22,86 116 24,08
113 23,16 123 24,08
122 23,47 134 24,38
135
23,77 148 24,99
Figure 1
Figure 2
1
@ 80 psi @ 90 psi
33.2 81 35.4 83
35.1 80 37.7 81
38.1 84 40.7 85
42.2 85 45.1 88
@ 5,5 bar @ 6,2 bar
Radius (m) LPM Radius (m) LPM
126 24,69 134 25,3
133 24,38 143 24,69
144 25,60 154 25,91
160 25,91 171 26,82
Turret cover
30°
™
@ 100 psi
37.5 86
39.5
40.0 83 42.1
43.1 90 45.4
47.8 90 50.3
@ 6,9 bar
Radius (m) LPM
142 26,21 150
151 25,3 159
163 27,43 172
181 27,43 190
Trajectory Nut
7°
30°
7°
