COMPACT 3.0
• Check and correct any possible poor contacts in connections or terminals of the
power cable.
• Charge or replace the battery.
!
(If the error persists, contact the Authorised Technical Service).
• Repair the possible obstruction of the centrifugal blower or the condenser fan; if
the error persists, replace the centrifugal blower or the condenser fan (remove
the outside cover of the unit in order to access the blower or the electro; for the
centrifugal blower, also remove the evaporator cover).
• Replace the 7.5A fuse. To access the condenser fan or centrifugal blower fuses, it
is necessary to take down the interior air distribution panel.
• Replace the electronic control.
!
(If the error persists, contact the Authorised Technical Service).
• Correctly connect the terminals of the compressor's electronic module. (See
attached wiring diagram).
• Replace the compressor electronic module(s).
• Replace the compressor(s).
• Check the pressure (the compressors disconnect after 6 bars); if necessary,
recover gas and load 330 g again per circuit.
!
To access the compressors, modules or load points it is necessary to take
down the unit's outside cover.
!
(If the error persists, contact the Authorised Technical Service).
