Troubleshooting
CLEANER DOES NOT TURN ON
There is no electricity in the wall socket:
(1) Disconnect cleaner from the power supply unit. (2)
Disconnect power supply from the wall socket, wait
30 seconds and reconnect. (3) Turn power on. If not
activated, connect the unit to a different wall socket.
Obstacle in the drive system of the cleaner unit:
(1) Check for obstacles and debris caught in the drive
belts.
(2) Clean and remove obstacles and debris if necessary.
Propeller is broken or seized due to accumulation of hair:
(1) Unscrew the outlet locker on the top outlet.
(2) Check if the propeller is broken or needs to be
cleaned.
CLEANER MOVES BUT DOES NOT PUMP WATER
Filters are dirty: (1) Remove the filters and clean them.
Propeller is broken or seized due to accumulation of hair:
(1) Unscrew the outlet locker on the top outlet.
(2) Check if the propeller is broken or needs to be
cleaned.
CLEANER PUMPS WATER BUT DOES NOT MOVE
Obstacle in the drive system of the cleaner unit:
(1) Check for obstacles and debris caught in the drive belts.
(2) Clean and remove obstacles and debris if necessary.
CLEANER STARTS AND SHUTS OFF AFTER A
SHORT TIME
Filters are dirty: (1) Remove and clean the filters. (2)
Restart the robot and try again.
Propeller is broken or seized due to accumulation of
hair: (1) Unscrew the outlet locker on the top outlet.
(2) Check if the propeller is broken or needs to be
cleaned.
Obstacle in the drive system of the cleaner unit:
(1) Check for obstacles and debris caught in the
drive belts.
(2) Clean and remove obstacles and debris if
necessary.
CLEANER DOES NOT PICK UP DIRT
Filters are dirty or have holes.
Clean as needed and verify that there are no holes
in the filters. If there are holes in the filter it needs to
be replaced.
Propeller is broken or seized due to accumulation
of hair.
Check if the propeller is broken or needs cleaning.
(1) Unscrew the outlet locker on the top outlet.
(2) Check if the propeller is broken or needs to be
cleaned.
CLEANER UNIT DOES NOT COVER THE ENTIRE
POOL
Clean the filters.
1. Verify that there is enough length of the floating
cable in the water to reach the far end of the pool.
2. Make sure that the floating cable is properly
spread out and is not tangled.
Propeller is broken or seized due to accumulation
of hair: (1) Unscrew the outlet locker on the top
outlet. (2) Check if the propeller is broken or needs
to be cleaned.
THE CLEANER DOES NOT CLIMB WALLS
(1) Make sure to clean the filters (2) Make sure
propeller isn't broken or seized with debris/hair.
Warning
Do not stay in the pool and remove
any and all items from the pool before
operating the robotic pool cleaner. Do
not leave the robot inside the pool if
unused.
The power supply must be connected
through a Ground Fault Current
Interrupter (GFCI USA) or a Residual
Current Device (RCD Europe) not
exceeding 30 mA.
The connection to the power must meet
local and national wiring rules.
All parts must be replaced with original
parts supplied by a BWT authorized
service center.
Keep out of children's reach.
Do not use the robotic pool cleaner if
you have added liquid flocculant or any
other clarifier to the pool
water. These substances obstruct and
damage the robot filters.
RC30 | RC40 ROBOTIC POOL CLEANER
7
