CUTTING HEIGHT
1
Pull out the height adjustment
lever 14 and the desired cutting
depth.
Caution! Make sure the appli-
ance is switched off and the
battery is removed.
BATTERIES
1
Lift the battery cover 7 and
push the battery (not included)
in until it clicks into place.
COLLECTION BAG
1
Lift the safety flap 4 and at-
tach the collection bag 13 to the
mower.
Caution! Wait until the blade
has come to a complete stop
before opening the safety flap.
REPLACING THE BLADE
1
Loosen the fastening screw A
and remove the worn blade.
Caution! Switch off and re-
move the battery first. Al-
ways use protective gloves.
LOWER HANDLE
3
Move the lower handle 12 to an
upright position and close the
lower locking lever 5.
Caution! Never use the appliance with open locking levers.
CONTROLS
2
In order to switch the appli-
ance on, press and hold the
safety button 1, tilt the appli-
ance backwards, pull the on/off
triggers 2 or 10 and release the
safety button 1.
SAFETY PLUG
2
Insert the safety plug directly
before starting and remove it
when interrupting or terminat-
ing the work.
2
If the collection bag 13 is se-
curely attached to the mower,
lower the safety flap 4.
Caution! Never run the appli-
ance without collection bag
in place.
2
Observe the rotation direc-
tion when replacing the blade.
Tighten the fastening screw A.
Warning! The blades should
only be replaced by author-
ized persons.
UPPER HANDLE
4
Install the upper handle 11 to
the lower handle 12 as shown,
using the upper locking lever 3
assembly.
