Bedienungs- und Installationsanleitung
Installation- and Operation Instruction
Meßgaskühler / Sample Gas Coolers EGK 4 S
6.2

Cleaning of the heat exchanger

The heat exchanger must be replaced in case of damage or when clogged. In the latter case we
recommend to check if the use of a filter will avoid repeating of such clogging.
Regard warnings mentioned above!
Loosen gas fittings and condensate drain fitting.
Pull out the heat exchanger upwards out of the cooler.
Clean the cooling nest (hole in cooling block).
Clean the heat exchanger until all impurities are disposed.
Grease the heat exchanger on the cooling surfaces with silicone grease.
Introduce the heat exchanger with turning movement into cooling nest.
Re-establish fittings for gas tubes and condensate drain.
6.3

Spare parts

To order spare parts please indicate type of cooler and serial no. For accessories and enhancement see data
sheets and/or catalogue.
The following parts are recommended for stocking:
Spare part
Fan
Electronic board
Temperature display
Temperature sensor
6.4

Attached documents

−
Data sheet EGK 4S:
−
Certificate of conformity:
DE+DA 45 0006
KX 45 0001
BX450004, 09/2006 ART. NR. 90 31 060
Part no.
230V 44 10 030
115V 44 00 03 0
230V 91 00 01 00 81
115V 91 00 01 00 99
44 00 003
PT100 45 10 016
15
