CV Name
47 Speed correction
48 Speed correction
49 Extended
configuration
50 Dimmer
51 Analogue mode of
operation
14
8040410920 VIII_2009.indd 14
Description
Speed correction forwards
Correction factor = value from CV47/63
Speed correction reverse
Correction factor = value from CV48/63
You can activate the support for the braking
sectors or deactivate the load control
Bit Description
0 Load control active
Load control inactive
2 Brake to 0 in the braking sector
Brake to driving stage in accor-
dance with CV52
3 Motorola** data format active
Motorola** data format inactive
4 DCC data format active
DCC data format inactive
5 Light dimming on
Light dimming off
6 Do not swap the light connections
(front/rear)
Swap the light connections
7 Braking only with brake signal
Braking with analogue voltage
If the Motorola** data format is deacti-
vated via Bit 3 and the DCC format via
Bit 4, the decoder does not receive any
more driving commands and can only be
programmed.
Determines the brightness of the light outlets
Analogue mode of operation settings
Bit Description
0 AC-detection off
AC-detection on
1 DC-detection off
DC-detection on
2 Lighting switchable
Lighting permanent
Value Works
range value
00 – 63 32
00 – 63 32
00 – 255 32
Value
0
1
0
4
0
8
0
16
0
32
0
64
0
128
00 – 32 32
01 – 03 3
Value
0
1
0
2
0
4
