ENGLISH
Pressure-controlled pilot valves
Technical data
Regulation ranges
CVP (LP)
0 bar → 7 bar (Pe) or
(0 psig → 100 psig) or
–0.66 bar → 2 bar
(20 in Hg → 28 psig)
CVPP (LP)
∆p = 0 bar → 7 bar
(0 psi → 100 psi)
The control pressure
must not exceed the
pressure of the medium
by more than 3 bar
Factory setting = lowest control
setting (slack spring)
Refrigerants HCFC, HFC, R717
–60°C → +120°C
Temperature range of
(–76°F → 248°F)
medium
Max. working PB = 17.5 bar (Pe)
pressure (183 psig)
Max. test pressure p' = 26.5 bar (Pe)
(277 psig)
Mounting
Type CVP or CVPP is mounted in the top cover of
the PM main valve. See gs. 2, 4 and 7.
The accompanying gaskets for CVP and CVPP
must be tted before mounting and the o-ring
must be lubricated with refrigeration oil.
2
Fig. 2. PM 1 + CVP (LP)
Fig. 3. PM 1 + CVP
Fig. 7. PM 1 + CVPP (LP)
Fig. 8. PM 1 + CVPP
The pilot valve has a width across ats of 32 mm
and should be tightened with a torque of 50 Nm
(5 kpm).
Type CVP or CVPP can also be mounted sepa-
rately in a valve housing, and used as a pilot
valve or an independent valve. See gs. 9 and
10. If the CVP/CVPP + valve body CVH is used as
a pilot valve the unit is mounted in a pilot line
with ow towards the main valve.
The nipple (6) on the CVPP is connected to
external control pressure.
CVP/CVP (LP) must not be exposed to pulsations
from the discharge side of the compressor.
Setting
CVP
Turning the setting spindle (2) clockwise
in-creases the opening pressure (higher
evaporating pressure or temperature) and vice
versa. One turn is equivalent to a change of 1 bar
(14.2 psi) for valves with range 0 bar to 7 bar and
approx. 0.5 bar (7.1 psi) for valves with range
–0.66 bar to +2 bar.
Coarse setting: Turn the spindle (2) anticlockwise
to stop. Then, turn it clockwise the number of
turns corresponding to the required opening
pressure.
Fine setting: This is done using a pressure gauge
after the refrigeration plant has run long enough
for the system to achieve balance.
CVPP
The method of setting is the same as described
for the CVP.
DKRCI.PI.HN0.C2.52 / 520H5282
Fig. 4. PM 3 + CVP
Fig. 5. PM 3 + CVP
Fig. 9
Fig. 10
Here, the opening pressure is equal to the
di erence between inlet and control pressures.
A change of control pressure will produce a
change of equal size in the main valve inlet
pressure (= the evaporating pressure).
Service
The CVP or CVPP can be cleaned out with
compressed air. Turn the spindle (2) completely
anti-clockwise and blow through the valve
against the normal direction of ow.
Spare parts and accessories
See Spare Parts catalogue.
The following text is applicable to the UL
listed products CVP (LP), CVPP (LP)
Applicable to all common non- ammable
refrigerants, including/excluding (+) R717 and
to non-corrosive gases/liquids dependent on
sealing material compatibility (++). The design
pressure shall not be less than the value outlined
in Sec. 9.2 of ANSI/ASHRAE 15 for the refrigerant
used in the system. (+++).
