ASSEMBLY
HARDWOOD PLATFORMS
MG-PRO47P-06
MG-PRO47P-4-06
MG-PRO9091P-06
MG-PRO9091P-4-06
1
2
ENGLISH
3
Hardware Qty
A 4
Hex Bolt ( 3⁄8 -16 x 1" Zinc)
B 4
Washer ( 5⁄16 " Zinc)
C 4
Flange Bolt
5⁄16
( -18 x 1" Black Zinc)
A B C
4
Hardware Qty
D 3
Bolt ( 1⁄ 4 -20 x 2" Bronze)
D
5
Hardware Qty
E 10
Screw (#6 x 1 5⁄8 ")
E
5
6
Hardware Qty
C Flange Bolt 12
5⁄16
( -18 x 1" Black Zinc)
ASSEMBLY COMPLETE
C
