50 m. When sensing objects such as power lines that
have a RCS of -10 dBsm, the effective detection range
is approximately 30 m. When sensing objects such
as dry tree branches that have a RCS of -15 dBsm,
the effective detection range is approximately 20 m.
Obstacle sensing may be affected or unavailable in
areas outside of the effective detection distance.
4. When sensing objects such as an inclined line, inclined
utility pole, or power line at an inclined angle against
the flying direction of the aircraft, the radar detection
performance will be affected since most of the
radar electromagnetic waves are reflected to other
directions. Fly with caution.
1. Comply with local radio transmission laws and
regulations.
2. The sensitivity of the radar module may be reduced
when operating several aircraft within a short distance.
Operate with caution.
3. The obstacle sensing functions are disabled in Attitude
mode.
4. The radar module is a precision instrument. DO NOT
squeeze, tap, or hit the radar module.
5. Before use, make sure that the radar module is clean
and the outer protective cover is not cracked, chipped,
sunken, or misshapen.
6. Operate with extra caution when flying over inclined
surfaces. The recommended maximum inclination at
different aircraft speeds are 10° at 1 m/s, 6° at 3 m/s,
and 3° at 5 m/s.
Firmware
To avoid component malfunction, serious injury, and
property damage, observe the following rule:
1. Keep people and animals at a safe distance during any
firmware update, system calibration, and parameter
setting procedures.
1. For safety, always update to the latest firmware version.
2. Only use official DJI firmware.
3. Make sure to update the remote controller's firmware
to the latest version after you update the aircraft's
firmware.
4. The remote controller may become unlinked from the
aircraft after updating. Re-link the remote controller and
aircraft.
5. Make sure to check all connections and remove the
propellers from the motors before performing the
firmware update.
DJI Pilot 2 App
1. Make sure to fully charge the remote controller batteries
before launching the DJI Pilot 2 App.
2. Read all safety tips, warning messages, and disclaimers
carefully. Be familiar with the related regulations in your
area. You are solely responsible for being aware of all
relevant regulations and flying in a way that is compliant.
Make sure to pay close attention in the following
situations:
a. Using the auto-take off and auto-landing features.
b. Setting the altitude beyond the default limit.
3. Land your aircraft immediately if a prompt appears in
the app.
4. Examine and check all warning messages on the aircraft
status list displayed in the app prior to each flight.
5. Cache the map data of the area where you intend to fly
the aircraft by connecting to the internet before each
flight.
4G Dongle
Dongle related functions are not supported in some
countries or regions. Comply with the local laws and
regulations.
1. A dongle and SIM card are required for some product
features in the DJI Pilot 2 app and users will bear the
cost of these extras.
2. Only use a DJI-approved dongle.
3. Only use SIM cards that are compatible with the dongle.
4. Make sure you mount the dongle and the SIM card
correctly. Otherwise, related functions will not be
available.
Product Care
Storage and Transportation
To avoid component malfunction, serious injury, and
property damage, observe the following rules:
1. Small parts, such as cables and straps, are dangerous
if swallowed. Keep all parts out of reach of children
and animals.
2. Make sure to remove the battery from the aircraft
during transportation.
3. Remove or empty the onboard storage during
transportation or when not in use to avoid damaging
the landing gear. Store the aircraft in a cool dry place.
Maintenance
To avoid component malfunction, serious injury, and
property damage, observe the following rules:
1. Clean all parts of the aircraft when the aircraft returns
to a normal temperature after flight. DO NOT clean the
aircraft immediately after operations are completed.
a. Make sure that the aircraft structure is completely
connected so that it can be washed directly with
water. It is recommended to use a spray washer
filled with water to clean the aircraft body and wipe
with a soft brush or wet cloth before removing
water residue with a dry cloth.
b. If there is dust or other foreign matter on the
motors or propellers, wipe them with a wet cloth
before cleaning the remaining water residue with a
dry cloth.
c. Store the cleaned aircraft in a dry environment.
2. Wipe the surface and screen of the remote controller
with a clean wet cloth that has been wrung out with
water daily after operations.
3. Inspect the aircraft every 100 flights or after flying for
over 20 hours:
a. Check for and replace worn propellers.
b. Check for loose propellers. Replace propellers and
propeller washers if needed.
c. Check for aging plastic or rubber parts.
4. DO NOT attempt to repair the aircraft. Contact DJI
Support or a DJI authorized dealer if any parts are
damaged.
1. Keep the protective cover of the radar module clean.
Clean the surface with a soft damp cloth and air dry
before using again.
2. Regularly wipe off dirt on the gimbal of the FPV gimbal
camera. Keep the FPV camera and the cameras of
the binocular vision system clean. Make sure that the
aircraft is powered off. First remove any larger pieces of
grit or sand then wipe the lens with a clean, soft cloth to
remove dust or other dirt.
3. In the event of a crash or collision, make sure to
thoroughly inspect every part of the aircraft and make
any necessary repairs and replacements before your
7
