EXPLODED-VIEW
PART NO.
1.
2.
3.
4.
5.
6.
7.
8.
9A/B.
10.
11.
12.
13.
14.
15.
16.
17.
18.
DESCRIPTION
Front Base Tube
Back Base Tube
Main Frame
Safety Frame
Adjustable Frame
Support Frame
Weight Plate Tube
Sarety Pin
Left /Right Safety Hook
50x45 Mid-empty Plug
Quick Pin
Rubber Ring
Hex Bolt M10x60
Hex Bolt M10x20
Washer M10
Washer M6
Nylon Nut M10
Nylon Nut M6
9
QTY
2
2
2
2
2
2
2
2
1
2
4
2
8
6
22
2
8
2
