Vitalizer Mk3-T – Manual
Specifications
Analog inputs & outputs; XLR (balanced)
Input impedance
Output impedance
Maximum output gain
Common Mode Rejection Ratio (1 kHz, 30 dB Gain)
Frequency range (30 dB Gain)
THD + N (0 dBu, 10 Hz – 22 kHz)
Noise (A-weighted)
Dynamic range
Internal Linear Power Supply with Toroidal Transformer
Operating voltage for analog audio
Operating voltage for relays and LEDs
Tubes anode voltage
Tubes heating voltage
Mains Power Supply
Mains voltage (selectable)
Fuse for 230 V
Fuse for 115 V
Power consumption
Dimensions & Weight
W x H x D (width x height x depth)
Unit weight
Shipping weight (incl. packaging)
8
22 kΩ
75 Ω
22 dBu
86 dB
10 Hz – 100 kHz
0.01 %
-88,6 dBu
110,6 dB
+/- 18 V
+ 12 V
+ 250 V
+ 12,6 V
230 V AC, 50; 115 V AC, 60 Hz
T 315 mA
T 630 mA
max. 20 W
482 x 44 x 237 mm
19 x 1.73 x 9.33 inch
3.4 kg
7.5 lbs
4.75 kg
10.47 lbs
