3.1 Einstellung PSPT02 / Adjusting PSPT02
• Ausgangsstrom am Meßgerät überprüfen (4 mA minimal ist werkseitig fest eingestellt).
• Fahren des Antriebs in die entgegengesetzte Endlage.
• Einstellung des maximalen Ausgangsstromes über Potentiometer P2 (MESSBEREICH),
bis das Meßgerät 20 mA anzeigt.
• Check the output current on the measuring instrument (4 mA as minimum signal is fixed).
• Drive the actuator to the opposite end position.
• Set the maximum output current using potentiometer P2 (SPAN), until the measuring
instrument displays 20 mA
3.2 Einstellung PSPT03 / Adjusting PSPT03
• Einstellen des minimalen Ausgangsstromes (0 mA oder 4 mA) über Potentiometer P1
(NULLPUNKT) anhand des Meßgeräts.
• Fahren des Antriebs in die entgegengesetzte Endlage.
• Einstellung des maximalen Ausgangsstromes über Potentiometer P2 (MESSBEREICH) bis
das Meßgerät 20 mA anzeigt.
• Set the minimum feedback current (0 mA or 4 mA) using potentiometer P1 (ZERO) verifying
by the measuring instrument.
• Drive the actuator to the opposite end position.
• Set the maximum feedback current using potentiometer P2 (SPAN) until the measuring
instrument displays 20 mA.
4. Technische Daten / Technical Data
Spannungsversorgung / Power supply
Eingang / Input:
Ausgang / Output:
Bürde / Impedance:
__________________________________________________________________________
PS Automation GmbH
Gesellschaft für Antriebstechnik
Philipp-Krämer-Ring 13
D-67098 Bad Dürkheim
________________________________________________________________________________________
4
24 VDC ±15%, geglättet / 24 VDC ±15%, smoothed
0-1000 Ohm
Tel.: <+49> (0) 6322 – 60 03-0
Fax: <+49> (0) 6322 – 60 03-20
e-mail:
info@ps-automation.com
Internet: www.ps-automation.com
BA_PSPT_0404 - 8031449
PSPT02
4-20 mA
600 Ohm
PSPT03
0-1000 Ohm
0(4) -20 mA
600 Ohm
