Dreame Bot Z10Pro Benutzerhandbuch Seite 7

Charging Contacts
Side Brush
Cliff Sensor
Main Wheel
Robot Sensors
Edge Sensor
Auto-Empty Base
Cliff Sensor
Upper Cover
Status Indicator
White: The base is plugged in
Breathing White: Robot is charging
Blinking Orange: Dust collection ba
gis full/Dust collection bag not
installed/Error
Signaling Area
Charging Contacts
Dust Intake
7
Charging Contacts
Omnidirectional Wheel
Main Brush
Cliff Sesnor
Main Wheel
Brush Guard Clips
Dust Intake
Laser Distance Sensor
Bumper
High Precision 3D
(3D Obstacle Avoidance Sensor)
