Function test

7 Function test
The function test is only activated if the motion
detector has already been connected.
Up to 10 minutes after connecting the device or estab-
lishing the power supply (if the device has already been
connected), the device LED (B) indicates detected mo-
vements. The LED flashes green with every movement
detected. In this way, the detection range and sensitivity
can be checked directly on the device.
8

Replacing batteries

If the battery symbol is displayed via the app or an emp-
ty battery is indicated on the device (see sec. „9.3 Error
codes and flashing sequences" on page 42), replace
the used batteries by two new LR6/mignon/AA batteries.
You must observe the correct battery polarity.
To replace the batteries of the motion detector, please
proceed as follows:
• Open the battery compartment (C) on the rear
by pushing the battery compartment cover (D)
down or by removing it from the wall mounting
bracket (E) (see fig. 4).
• Insert two new 1.5 V LR6/mignon/AA batteries
into the battery compartment, making sure that
you insert them the right way round (see figure 6).
