Repo Function - Power Walker VFI 10000P/RT LCD Benutzerhandbuch

Installation procedure:
Connected by USB to a PC or notebook, the Software enables
communication between the UPS and the computer. The UPS software
monitors the status of the UPS, shuts down the system before the UPS
is exhausted and can remotely observe the UPS via the Network
(enabling users to manage their system more effectively). Upon AC
failure or UPS battery low, UPS takes all necessary actions without
intervention from the system administrator. In addition to automatic file
saving and system shut-down functions, it can also send warning
messages via pager, e-mail etc.

Use the bundled CD and follow the on-screen instructions to
install the software WinPower.

Enter the
511C1-01220-0100-478DF2A

After the software is successfully installed, the communication
with UPS has been established and an green icon will appear in
the system tray.

Double-click the icon to use the monitor software (as above).

You can schedule UPS shutdown/start-up and monitor UPS status
through PC.

Detail instructions please refer to the e-manual in the software.
Check www.powerwalker.com/winpower.html
time to get the latest version of monitoring software.

9.4 REPO Function

The Remote Emergence Power Off interface provides an emergence
power off function. When the REPO function is enabled, once the EPO
port is plugged in, the UPS would shut off the output and enter into EPO
mode, and the UPS would not respond anything command unless the
port is pulled out.
60
following serial No. to install
from time to
software:
