4. Power cables connection & Startup
This section explains:


Access to terminal block



Common input sources connection


Separate input sources connection

Frequency converter connection

UPS initial startup
Use cable cross section and protective device specification
Model
Protective earthing conductor
Min cross section
Input L, N, G
Min conductor cross section
Input fuse
Output L,N,
Min conductor cross section
External Battery Cabinet
Positive Pole(+), Negative
pole(-), Neutral Pole
Min conductor cross section
External Battery Cabinet Fuse
in Positive Pole(+), Negative
pole(-), Neutral Pole
The UPS does not have an automatic protection device against current
backfeed. It is suggested that install an external isolating device ,which
is shown in the following illustration. Check for hazardous voltage
between all terminals before operating on this circuit.
6K
2
4mm (10AWG)
2
4mm (10AWG)
60A
2
4mm (10AWG)
2
4mm (10AWG)
60A
10K
2
6mm (8AWG)
2
6mm (8AWG)
80A
2
6mm (8AWG)
2
2.5mm *2 (12AWG*2)
80A
