7) Pressing
one UPS of the system, then the system will start to turn on and
enter line mode.
8) Regulate the output voltage of the each UPS separately, and
check if the output voltage difference between the two ups is
less than 0.5V. If the difference is more than 0.5V, the UPS
need to be regulated.
9) If the difference output voltage is less than 0.5V, switch on the
output breakers for the two UPS separately and switch on the
main O/P breakers, then the system will work normally in
parallel.
■ The output wiring requirement as follows:
● When the distance between the UPS in parallel and the breaker
panel is less than 10 meters, the length difference between
input and output cable of the UPSs is required to be less than
20%.
● When the distance between the UPS in parallel and the breaker
panel is more than 20 meters, the length difference between
input and output cable of the UPSs is required to be less than
5%.
How to join a new UPS to a parallel system:
1) Firstly a main maintenance mechanical switch or static switch
should be installed for the parallel system.
2) Regulate the output voltage of the new UPS: check if the output
voltage difference between the new UPS and the parallel
system is less than 0.5V.
3) Ensure the bypass of the parallel system is normal and the
bypass setting is "enable", then press the
the UPS, then UPS will work in bypass mode.
Set the main maintenance switch or static switch from "UPS" to
4)
"BPS", then switch off the main output breaker and the input
breaker and mains breaker, then the UPS will shut down.
button continuously for more than 1 second for
button to turn off
29
