Alpha 800 Instruction Manual
Valid voltage ranges for @ and @/@ for each module are as follows:
Module Voltage Range
AA @ = 4.5 – 6.2V
BB @ = 4.5 – 6.5V
C @ = 5 – 16V
E @/@ = 5 – 16V / 5 – 16V
EQ @/@ = 4.5 – 5.5V / 2.7 – 3.9V
G @ = 17.5 – 29V
J @ = 30 – 48V
L @ = 1.8 – 3.2V
N @ = 18 – 32V
Q @ = 2.7 – 3.9V
S @ = 2.5 – 5.7V
U @ = 10 – 21V
Z @ = 4.5 – 5.5V
Secondary Options:
Option Description
_MG Provides a module good signal with indicates output voltage is within limits.
_PA Forces paralleled modules to share load current. Additionally it also provides the
module good signal.
_PP Provides either of the following functions:
a) Reduces module current limit and caters for paralleled modules with busbar
linking. For use with modules providing a max output of up to 16V only; or
b) Identical to _PA except that the module is paralleled at the output of the module
with busbar linking.
_IN Provides an external signal which may be used to inhibit the output of the module.
_RP Provides remote programming of the module output voltage.
_D Provides a delay to the turn on time of the output.
Note:
The RP option can only be used on modules with output voltages rated up to 16V. Not for use with a module voltage range of 18-
29V or twin output modules.
B, BB, Z, Q, M, G, C, and D modules fitted with PP options are not permitted in slot 7.
Only one G module is permitted on each converter.
ELECTRICAL & THERMAL RATINGS:
Input parameters
NOMINAL INPUT VOLTAGE RANGE
MAX. INPUT VOLTAGE RANGE
INPUT FREQUENCY
MAXIMUM INPUT CURRENT
INRUSH CURRENT
* DC for specific Non-standard, 60950-1 versions only.
Module Voltage Range
A @ = 4.5 – 5.5V
B @ = 4.5 – 5.5V
D @ = 18 – 29V
EB @/@ = 4.5 – 5.5V / 4.5 – 5.5V
F @ = 9 – 15.5V
H @/@ = 18 – 32V / 18 – 32V
K @ = 18 – 29V
M @ = 5 – 16V
P @/@ = 18 – 29V / 5 – 16V
R @ = 2.7 – 3.9V
T @ = 1.8 – 3.2V
W @ = 4.5 – 5.5V
-
94.5 - 240VAC or 133VDC-328VDC*
85-264VAC or 120-360VDC*
47-63Hz
16 AMPS or 11 AMPS DC
<50 AMPS
Page 15 of 29
-
17026 issue 23, October 2021
