Alpha 800 Instruction Manual
Safety Approvals:
UL60950-1, and CSA22.2 No.60950-1 - UL Recognised. C-UL for Canada.
UL62368-1, and CSA22.2 No.62368-1 - UL Recognised. C-UL for Canada
IEC / EN62368-1 - CE and UKCA mark.
IEC/EN60950-1, IEC/EN62368-1 and/or IEC/EN60601-1 (For LL, TL and RL filters only) - CB Report and Certificate.
CE marking when applied to any Alpha 800 product indicates compliance with the Low Voltage Directive in that it
complies with EN62368-1 and with RoHS Directive.
UKCA marking when applied to any Alpha 800 product indicates compliance with the Electrical Equipment (Safety)
Regulations 2016 in that it complies with EN62368-1 and with the Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment Regulations 2012
UL/CSA 60601-1 - UL + C -UL approval (For LL, TL and RL filters only).
Fusing: Internal fuse (FS101): 20A/250V fast acting HBC fuse 6.3x32 mm.
Symbols:
AC DC
PRODUCTS COVERED
Note: All output voltages/variants may not be available as standard units, refer to datasheet for standard
product range. These (and other variants) may be available as non-standard or custom units, please contact
our sales team for details.
Unit Configuration Code:
Alpha 800 and CA800 are identical.
Alpha 800 or CA800 may be followed by: TL, RL, LL or ML
Where TL = Tiny leakage input filter
RL = Reduced leakage input filter
LL = Low leakage input filter
ML = Medium leakage input filter
May be followed by up to seven of the following:
@ followed by AA, A, BB, B, C, D, F, G, J, K, L, M, N, Q, R, S, T, U, W, or Z,
optionally followed by _MF, _X, _XL, MFL, MFE, MFU, MFV or _MFV, _PA, _IN, _PP, _RP,_D
or B/S
or @/@ (Where / may be replaced with a _) followed by: E, EB, EQ, H, or P:
Where @ and @/@ = applicable voltage range and the following one or two letters are the module type.
_MF, MFE = Mains fail option (may also be called X).
MFU = Mains fail option with uncommitted output connections.
MFV = Mains fail option with VME bus
MFL, _XL = Mains fail latch
_PA, _PP, _IN, _RP = Secondary module options.
B/S = Blanking slot which occupies one 23mm slot.
Only up to seven 23mm slots may be filled up per unit, noting that all modules occupy one 23mm slot except for AA, A, F, G, J, K,
R, S and T modules which occupy two 23mm slots. All primary MF options can only be fitted in slot 1.
EARTH N – Neutral
Page 14 of 29
L – Live
17026 issue 23, October 2021
