ekey flush mount back box integra
Note on the document
These operating instructions are not subject to
updating. The most up-to-date version of
these documents can be
www.ekey.net. Subject to optical and tech-
nical amendments, as well as printing and
typing errors.
Scope of delivery
Art.No. 101300 ekey flush mount back box
integra:
1 x ekey flush mount back box integra
2 x cylinder head screws M2.5 x 25
1 x mounting instructions
Purpose
The ekey flush mount back box integra is an
installation aid for mounting the fingerprint
scanner ekey FS IN in walls.
Dimensions
42mm x 87mm x 25mm
Subject to optical and technical amendments, as well as printing and typing errors
ID28/57: Version 1, 2011-07-27
Creating the recess
A recess in the wall with the following minimal dimensions has to be created for the ekey flush
mount back box integra.
Figure 1
90 mm
found at
Mounting
Figure 2
Decorative plate
28 mm
45 mm
ekey flush mount
ekey FS IN finger-
back box integra
print scanner
Srews
M2.5 x 25
Cable feed
Bend up claws für
fixing
When creating the recess make sure
that you observe the specified
mounting height for the fingerprint
scanner!! For the ekey FS IN it is at
least 155cm.
Safety guidelines
The ekey flush mount back
box integra is made of
metal and therefore con-
ducts electricity. Observe
the corresponding safety
distances and regulations
on electrical systems with
hazardous electrical volt-
age as per the Low Voltage
Directive.
ekey biometric systems GmbH
Lunzerstraße 89
A- 4030 Linz
www.ekey.net
