Product overview

1 Locking sleeve
2 Chuck
3
Auxiliary handle
4
Power cord
5 Rear handle
6 Rear hammer-drill/ drill switch
7 Top hammer-drill/ hammer switch
8 On/ off switch
9 Grease box cover

Using the tool

1. To switch on the tool, press and hold the
on / off switch 8.
2. Make sure your workpiece can not slip.
Start working, while holding the tool firm-
ly with both hands.
3. To switch off the tool, release the on / off
switch 8.
APPLY HANDLE
1 Release the noose of the auxiliary han-
dle 3 and slide it onto the rotary ham-
mer.
Caution! Make sure the tool is
switched off and unplugged.
FIT CHISEL OR DRILL
1 Slide back the locking sleeve 1. Fit
the SDS-plus chisel or drill into the
chuck 2.
Caution! Make sure the tool is
switched off and unplugged and
wear protective gloves.
86 DE

Intended use

The tool is intended for hammer drilling in con-
crete, brick and stone. It can be set to rotation
only for drilling in metal and wood and also for
hammer function only for chiseling brick, con-
crete and masonry products. The tool is not
intended for commercial use.
Any other use or modification to the tool is
considered as improper use and could cause
considerable dangers.
2 Set the desired angle and tighten the
auxiliary handle 3
2 Make sure that the chisel or drill is
fully inserted.
Release the locking sleeve
if the chisel or drill is securely fixed.
To remove the chisel or drill, slide back
the locking sleeve
chisel or drill.
securely.
1 and check
1 and pull out the
