CONNECTION

1
9
3
8
10
* necessary if water pressure
> 0.5 MPa (5 bar)
HEATING TIME OF THE WATER DEPENDING ON PV-POWER
power
200 W
400 W
550 W
NOTE
The values given in the table are intended as a gui-
deline. The heating times depend on many factors
(power, ambient air temperature, water withdrawal)
and may differ from reality. The greater the connec-
HEATING TIME OF THE WATER WITH 230V REHEATING
power
1500 W
2
5
6* 4
7
PVB-30-AC
6°C / h
12 °C / h
16 °C / h
PVB-30-AC
45°C / h
1
Water heater
2
Water inlet
3
Water outlet
4
shut-off valve*
5
combined check and
pressure relief valve
6
Pressure reducing
valve*
PVB-80-AC
2 °C / h
4,5 °C / h
6 °C / h
ted photovoltaic power, the more the water can be
heated on days with low solar radiation. The water
is heated with a maximum power of 550 W, even if
more photovoltaic power is available.
PVB-80-AC
15°C / h
9
7
Cold water
8
Hot water
9
Device plug for
external mains current
10
Power cable*
*not included
