3.3 Montage

Anbringung der Wandmontageplatte nur durch autorisiertes Fachpersonal und
!
Elektriker. Die tci GmbH kann keine Haftung für die montierte Wandplatte und
deren Funktion übernehmen. Eine Prüfung durch Fachpersonal ist erforderlich.
Montage nur senkrecht!
Montage nur im spannungsfreien Zustand der Zuleitungen. Montage nur im
spannungsfreien Zustand der Zuleitungen.
Schritt 1:
Entfernen Sie die Systemträgerabdeckung. Nehmen
Sie die Wandmontageplatte als Bohr-schablone.
Positionieren Sie die Platte so, dass die Aussparung
deckungsgleich mit der Unterputzdose ist. Durch
diese Öffnung werden alle Zuleitungen gelegt. Über-
tragen Sie die 4 Befestigungslöcher auf die Wand.
Wählen Sie je nach Wandbeschaffenheit eine
geeignete Schraubenart und Länge aus.
Empfehlung zur Positionierung des ambiento:
Die richtige Position des ambiento hängt von
39
Körpergröße des
19,5
Benutzers ab.
39
4x Bohrungen für
Wir empfehlen:
24,5
39
Senkschrauben M5
4x hole for
Displaymitte ~ 1650 mm
counter screw M5
vom fertigen Fußboden.
Freiraum für
24,5
Anschlüsse
24,5
Space for
connections
19,5
101
Schritt 2:
Setzen Sie Löcher für Senkkopfschrauben [M5].
Ludwig-Rinn-Straße 10-14 • D- 35452 Heuchelheim/Gießen • Phone: +49 6 41-9 62 84-0 • Fax: +49 6 41-9 62 84-28 • www.tci.de
Seite 12 von 40
19,5
4x Bohrungen für
Senkschrauben M5
4x hole for
counter screw M5
19,5
Freiraum für
Anschlüsse
Space for
4x Bohrungen für
connections
Senkschrauben M5
19,5
4x hole for
counter screw M5
101
153
120
Freiraum für
Anschlüsse
Space for
connections
19,5
101
153
120
153
120
19,5
3.3 Mounting
39
4x Bohrungen für
Senkschrauben M5
4x hole for
counter screw M5
Mounting of the wall mounting plate only by authorized technical personnel and
!
Freiraum für
Anschlüsse
electrician. tci GmbH assumes no liability for the installed wall plate and their
24,5
Space for
connections
function. An examination by technical personnel is necessary.
19,5
Only mount vertically!
101
153
120
Assemble only in a de-energized condition.
Step 1:
Remove the cover of the system unit. Use the wall
fastening panel as drilling template. Position the
board so that the oval cavity is congruent with the
in-wall power outlet/socket. All supply lines will be
routed through this hole. Assign the 4 screw holes
in the wall. Choose a suitable screw type and length
depending on the wall composition.
Positioning recommendation of the ambiento:
The right position of the
ambiento depends on
the user's body height.
We recommend: Display
middle ~ 1650 mm from
the finished ground floor.
Step 2:
Drill holes for countersunk screws [M5].
Ludwig-Rinn-Straße 10-14 • D- 35452 Heuchelheim/Gießen • Phone: +49 6 41-9 62 84-0 • Fax: +49 6 41-9 62 84-28 • www.tci.de
19,5
39
4x Bohrungen für
Senkschrauben M5
4x hole for
counter screw M5
