FR 200 • Operating Manual

Fit the fine adjustment mechanism (FE)

A) Remove the adjustment rod
B) Adjustment rod: Pull out the upper pin
C) Adjustment rod: Pull out the lower pin
D) Adjustment rod with FE: Fit the lower pin
E) Adjustment rod with FE: Fit the upper pin
F) Adjustment rod with FE: fitted
Operate the precision adjustment mechanism by turning the grey handle (see arrow - Fig. F).
10
A
D
A
D
B
E
B
E
Tools
C
F
C
F
