INDex
Pruduct illustration
Part description
List of items
Specification

Field of application

Assembly
Dismantling
Handling + details
Accessories
Declaration of conformity
lIST Of ITeMS
1 Hull
1 Bow seat-board
1 Rear seat-board
1 Repair kit incl. valve key and bayonet
adapter
SpeCIfICaTION
Length:
Beam:
Net weight:
No of persons:
Carrying capacity:
Operating pressure:
Motor output:*
Motor weight:*
WW-Class:
Norm:
Category:
* = with outrigger only!
Page
2
2
7
7
7
7
7
9
10
11
405 cm
95 cm
20 kg
3 Erwachsene
350 kg
0,3 bar
2,2 kw - 3 PS
17 kg
3
ISO-EN 6185/III
D
fIelD Of applICaTION
► Canoe on lakes, rivers and sheltered
coastal close waters.
► White-water suited boat to level of diffi-
culty grade 3, - none obstructive pas-sa-
ges, high inordinate waves, large swell,
rolling, swirling water, surge and torrent
wash.
WarNING: White-water
with spray-cover, or bailing required, pos-
sible for experienced paddlers only.
► Motorisation to max 2.2KW/ 3HP - With
outrigger only!
aSSeMBly
► Open and empty the carton, of your boat
and the footrests.
► Check the list of items to ensure no parts
are missing.
► Remove the wrapping foil and unroll the
boat.
► Inflate bottom and side tubes till they
reach approximate final shape.
► Remove the knurled nuts of the seat-
boards and insert them from underneath
into the seat-board eyelets, fasten the
nuts.
IMpOrTaNT
short seat-board aft, long seat-board for-
ward
► Now only inflate your boat to full opera-
ting pressure (0.3 bar).
exploration,
7
