Handbuch LxT
LD Model: LxT1, Serial #: 0010, Normalized to 251.19Hz @ 0°
Tested 11/23/05 12:25:57 by Alex T.
Note: PRMLxT1/0155 and 377B02/100650
Reference Mic: B&K Model: 4189, Serial Number: 2440346, Tested: 11/23/05 08:44:02
6.0 dB
2.0 dB
-2.0 dB
-6.0 dB
-10.0 dB
-14.0 dB
-18.0 dB
Mic 1258.93 Hz
°
Abb. A-8: LxT mit dem Mikrofon 377B02: 1258.93Hz,
2511.89Hz, 5011.87Hz und 10000.00Hz.
LD Model: LxT1, Serial #: 0010, Normalized to 251.19Hz @ 0°
Tested 11/23/05 12:25:57 by Alex T.
Note: PRMLxT1/0155 and 377B02/100650
Reference Mic: B&K Model: 4189, Serial Number: 2440346, Tested: 11/23/05 08:44:02
6.0 dB
2.0 dB
-2.0 dB
-6.0 dB
-10.0 dB
-14.0 dB
-18.0 dB
Mic 1584.89 Hz
Abb. A-9: LxT mit dem Mikrofon 377B02: 1584.89Hz,
3162.28Hz, 6309.57Hz und 12589.25Hz.
0°
Mic 2511.89 Hz Mic 5011.87 Hz
0°
Mic 3162.28 Hz Mic 6309.57 Hz
90°
Mic 10000.00 Hz
90°
Mic 12589.25 Hz
A-25
