Larson Davis SoundTrack LxT Benutzerhandbuch Seite 218

A-24
LD Model: LxT1, Serial #: 0010, Normalized to 251.19Hz @ 0°
Tested 11/23/05 12:25:57 by LD
Note: PRMLxT1/0155 and 377B02/100650
Reference Mic: B&K Model: 4189, Serial Number: 2440346, Tested: 11/23/05 08:44:02
2.0 dB
-2.0 dB
-6.0 dB
-10.0 dB
-14.0 dB
-18.0 dB
-22.0 dB
Mic 251.19 Hz
Abb. A-6: LxT mit dem Mikrofon 377B02: 251,19Hz.
LD Model: LxT1, Serial #: 0010, Normalized to 251.19Hz @ 0°
Tested 11/23/05 12:25:57 by Alex T.
Note: PRMLxT1/0155 and 377B02/100650
Reference Mic: B&K Model: 4189, Serial Number: 2440346, Tested: 11/23/05 08:44:02
6.0 dB
2.0 dB
-2.0 dB
-6.0 dB
-10.0 dB
-14.0 dB
-18.0 dB
Mic 1000.00 Hz Mic 1995.26 Hz
Abb. A-7: LxT mit dem Mikrofon 377B02:
1000.00Hz, 1995.26Hz, 3981.07Hz und 7943.28Hz.
0°
90°
0°
Mic 3981.07 Hz Mic 7943.28 Hz
Handbuch LxT
90°
