Inputs
M12 socket
sensor supply L+
sensor supply L-
functional earth
Data bit
input
socket
PIN
Note
In the AS-i network the module functions as two independent A/B slaves.
Addressing
The address for the two slaves is set to 0 at the factory.
Addressing with the addressing unit AC1154
For addressing the module, a 2/4-wire jumper is connected to the M12
plug (AS-i).
In the factory setting, initially only the first slave gives a signal on
address 0. It can be addressed to any address between 1A...31B. Once
this slave is addressed, the second slave is automatically indicated on
the display of the AC1154 with address 0 and can then also be addres-
sed to any address between 1A...31B.
6
Pin
1
3
5
D0
1
I-1/2
I-1/2 I-2
4
2
AS-i
D1
D2
2
I-3/4
4
1: AS-i +
3: AS-i -
5: FE
D3
3
4
I-3/4 I-4
4
2
4
