Information Concerning These Instructions; Hazard Information - HomeMatic RS485 Installationsanleitung

Table of Contents
1

Information concerning these instructions . . . 23

2

Hazard information . . . . . . . . . . . . . . . . . . . . . 23

3 Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4 General system information on HomeMatic . . . 26
5 General information on the bus system . . . . . 27
5.1 General information on the installation . . . . . . 27
5.2 Topology of the bus system . . . . . . . . . . . . . . 29
6 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
7 Allocation of button inputs. . . . . . . . . . . . . . . . 34
7.1 Teaching button inputs to actuator channels . . . . 34
7.2 Clearing assignments of button inputs to actua-
tor channels. . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8 Maintenance and cleaning . . . . . . . . . . . . . . . 37
9 Technical specifications . . . . . . . . . . . . . . . . . 38
22
1 Information concerning these
instructions
Read these instructions carefully before beginning
operation with your HomeMatic components.
Keep the instructions handy for later consultation!
Please hand-over the operating manual as well when
you hand-over the device to other persons for use.
Symbols used:
Attention! This indicates a hazard.
Note. This section contains additional important
information!
2 Hazard information
The described actuators are part of a building
installation. When planning and setting up
electrical systems, the pertinent standards and regula-
tions of the respective country of installation are to be
observed.
