Endress+Hauser Prosonic Flow B 200 Einbauanleitung Seite 4

Replacing cable harness, cable gland
i
8 mm
m
2 Nm
(1.5 lbf ft)
14 mm
6 Nm
(4.4 lbf ft)
2 Re-assembly
Unless otherwise specified, installation is the reverse of the removal procedure.
The following must be noted:
a
1.) Feed the cables labeled "A" through the neck cable entry, in direction
of flow (1).
Feed the cables labeled "B" through the neck cable entry, in oppesite
direction of flow (2).
The cable insulation must be flush mounted to the metric reducter (3, 4).
Otherwise the cable gland is not tight.
4
j
A0013772
n
(10.3 lbf ft)
7 Nm
(5.2 lbf ft)
22 mm
A0016352
k
14 mm
A0016484
o
14 Nm
A0016353
b
A0016490
2.) Plug in the shorter cables into the higher sensors (1).
Plug in the longer cables into the lower sensors (2).
l
22 mm
A0016291
A0016352
A0016352
A0016491
