OPERATION
Connect the connection cable of the power-unit with the DC IN-socket of the device. Plug the power unit into
your outlet. After you connected the effect to the mains, the LED FE-400 Hybrid Flower Effect starts running.
You can do without a controller as the device features a built-in microphone, which provides automatic sound
control.
With the Mode-button on the device you can set Auto or Sound Control Mode.
Sound Control Mode: color change controlled by sound
Auto Mode: Automatic color change
Remote control
1. The remote control is supplied with battery inserted.
2. An insulating foil between the battery and the battery contacts prevents the battery from being
discharged during storage. Prior to the first operation remove the foil from the battery support on the
rear side of the remote control. Otherwise, operation of the remote control is not possible.
3. When actuating a button, always hold the remote control in the direction of the sensor. There must
be visual connection between the remote control and the sensor.
4. If the range of the remote control decreases (10 meters as a maximum), replace
the battery. For this purpose, on the rear side of the remote control press the
small bar with the groove to the right and at the same time remove the battery
support.
5. For operation, one 3 V button cell type CR 2025 is required. When inserting, pay attention that the
positive pole of the button cell shows upwards in the support.
Danger of explosion when battery is replaced improperly. Only replace by the same type. Please dispose of
old and used batteries properly. Batteries are hazardous waste and should not be disposed of with regular
You can select the programs by pressing the buttons on the controller as follows:
CAUTION!
domestic waste!
ON/OFF: Switch the device on and off.
+
Brightness
(increases the brightness)
-
Brightness
(decreases the brightness)
Auto 1/2/3: Auto modes
B1: Red ON
B2: Green ON
B3: Blue ON
B4: Color fading mode 1
B5: Color fading mode 2
B6: Color fading mode 3
Strobo-flash: Strobe mode
Music 1: Sound controlled color switching
Music 2: Sound controlled strobing
Lamp 1: LEDs of the faceted half sphere ON/OFF
Lamp 2: Surrounding LEDs ON/OFF
+/-
: Adjust the strobe speed under Strobo-flash or adjust the
sensitivity under Music 1
14/15
00093175, Version 1.0
