To ensure that items are properly packaged
and delivered when you send them to us,
please contact our customer service or the
point of sale at which the equipment was
purchased.
When shipping or disposing of batteries and
cordless tools, always ensure that they are
packed individually in plastic bags to prevent
short circuits and fi res.
To ensure that the battery pack provides long ser-
vice, you should take care to recharge it promptly.
You must recharge the battery pack when you
notice that the performance of the device drops.
Never allow the battery pack to become fully di-
scharged. This will cause it to develop a defect.
5.2 Battery capacity indicator (Fig. 5)
Press the switch for the battery capacity indicator.
The battery capacity indicator shows the charge
status of the battery using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED fl ashes:
The battery is empty, recharge the battery.
All LEDs fl ash:
The battery pack has undergone exhaustive di-
scharge and is defective. Do not use or charge a
defective battery pack.
5.3 Installing the battery (Fig. 6-7)
Push the battery into the battery mount provided.
When the battery is positioned as in Fig. 7, make
sure that the pushlock button latches in place!
To remove the battery, press the pushlock button
and take out the battery (Fig. 8).
6. Operation
The area to be cut must fi rst be cleared of stones
and other solid objects. The safety lock-off (Fig. 1/
Item 2) prevents the tool being started unintenti-
onally.
Switching on (Fig. 9)
Activate the safety lock-off by pressing it and
pressing the ON/OFF switch at the same time.
Anl_GC_CG_18-1_Li_SPK9.indb 18 Anl_GC_CG_18-1_Li_SPK9.indb 18
GB
Switching off (Fig. 10)
To switch off the equipment, let go of the ON/OFF
switch.
6.1 Cutting grass
Allow the grass cutter to glide above the ground.
The best results are achieved when the lawn is
dry.
When you notice a drop in cutting performance,
re-charge the tool immediately so that the battery
does not become fully discharged.
6.2 Changing the blades
Warning! Risk of injury!
To prevent injuries, slide the blade guard
over the blade.
To remove the blade, press the release mecha-
nism (Fig. 11) and take out the blade as shown in
Fig. 12.
Once you have removed the blade you will be
able to see the toothed wheels of the gear unit.
Make sure that no dirt gets into the gear unit when
you change the blade.
To assemble, proceed in the reverse order.
Caution! The blade will fall out when the release
mechanism is pressed (Fig. 11)!
Fitting the blade (Fig. 13-14)
Insert the narrow side of the blade housing in the
equipment housing. Press the blade release me-
chanism and then the blade housing against the
equipment housing until it makes an audible click.
7. Cleaning, maintenance and
ordering of spare parts
Danger!
Remove the rechargeable battery/batteries.
7.1 Cleaning
•
Keep all safety devices, air vents and the
motor housing free of dirt and dust as far as
possible. Wipe the equipment with a clean
cloth or blow it with compressed air at low
pressure.
•
We recommend that you clean the device
immediately each time you have finished
using it.
•
Clean the equipment regularly with a moist
cloth and some soft soap. Do not use
cleaning agents or solvents; these could
attack the plastic parts of the equipment. En-
- 18 -
