REPLACEMENT PARTS • ERSATZTEILE • PIÈCES DE RECHANGE • PEZZI DI RICAMBIO
Part # English
TLR235010 Screw, G3 Shock Cup (8)
TLR235011 Flat Head Screws, M2.5 x 4mm (10)
TLR235012 Set Screw, M3 x 20mm (8)
TLR235014 Cap Head Screws, M2.5 x 10mm (10)
TLR235015 Button Head Screws, M3 x 4mm (10)
TLR236007 Ball Stud, 4.8 x 12mm (4)
Black Alum Flanged Locknut, M4 x
TLR236009
0.7mm x 7mm (4)
TLR236011 Ball Stud Low Mount 4.8 x 5mm (4)
TLR237000 5 x 8 x 2.5mm Bearing (2)
TLR2930 22 Alum Std Hexes
TLR2951 Tungsten Carbide Diff Balls, 3/32 (14)
TLR2952 Silicone Diff Grease, 8cc
TLR2954 Drive Rings (2)
TLR2955 Outdrive Set
TLR330010 Low Front Wing Clear with Mount (2)
Bell Crank Set, Aluminum, Black:
TLR331034
22 5.0
TLR331035 Drag Link, Aluminum, Black: 22 5.0
Servo Mount, Aluminum, Black: 22
TLR331036
5.0
TLR331037 Carbon Wing Washer (2): 22 5.0
Carbon Electronics Mounting Plate:
TLR331038
22 5.0
TLR332073 VHA Rear Axle, Buggy (2): 22 5.0
TLR332074 VHA CVA Rebuild Set (2): 22 5.0
TLR333005 Shock Body, 36.5mm, G3 3.5 (1)
TLR333006 Shock Body, 42mm, G3 3.5 (1)
TLR333007 Shock Shaft, 42.7mm, G3 3.5 (1)
TLR333008 Shock Shaft, 48.7mm, G3 3.5 (1)
TLR334049 2/4mm Front Alum Fr Inserts
Deutsch
Schraube, G3 Stoßdämpfer-Teller (8)
Flachkopfschrauben, M2,5 x 4mm
(10)
Schraubenset, M3 x 20mm (10)
Zylinderkopfschraube, M2.5 x 10mm
(10)
Rundkopfschraube, M3 x 4mm (10)
Kugelkopf mit Gewinde 4.8 x 12mm
(4)
Aluminium-Kontermutter, schwarz, mit
Flansch, M4 x 0,7 mm x 7 mm (4)
Kugelzapfen, niedrig montiert 4,8 x
5 mm (4)
5 x 8 x 2.5mm Lager (2)
Hintere Mutter, Standardbreite,
Aluminium
Tungsten Carbite Kugel 3/32 (14)
Differentialfett/8cc
Gleitringe Diff
Antriebsklauen Set
Niedriger vorderer Flügel transparent
mit Halterung (2)
Winkelhebel, Satz, Aluminium,
schwarz: 22 5.0
Lenkzwischenstange, Aluminium,
schwarz: 22 5.0
Servohalterung, Aluminium, schwarz:
22 5.0
Tragfl ächen-Unterlegscheibe, Karbon
(2): 22 5.0
Elektronik-Halterungsplatte, Karbon:
22 5.0
VHA Hinterachse, Buggy (2): 22 5.0
VHA CVA Nachbausatz (2): 22 5.0
Stoßdämpfergehäuse, 36,5 mm, G3
3,5 (1)
Stoßdämpfergehäuse, 42 mm, G3
3,5 (1)
Kolbenstange, 42,7 mm, G3 3,5 (1)
Kolbenstange, 48,7 mm, G3 3,5 (1)
2/4 mm Front Alum. Fr. Einsätze
Français
Vis, coupelle d'amortisseur G3 (8)
Vis FHC M2.5 x 4mm
Vis sans tête, M3 x 20mm (10)
Vis BTR M2.5 x 10mm (10)
Vis à tête bombée M3 x 4mm (10)
Rotules à visser 4,8 x 12mm (4)
Contre-écrou en aluminium à collet
noir, M4 x 0,7 mm x 7 mm (4)
Piton à rotule, surbaissé, 4,8 x 5
mm (4)
Roulements 5 x 8 x 2.5mm (2)
Hexagone arrière en aluminium,
largeur standard
Bille de différentiel en carbure de
tungstène, 3/32 (14)
Graisse silicone pour diff, 8cc
Plateau de différentiel (2)
Noix de sortie de diff
Aile avant basse, transparente, avec
support (2)
Ensemble de leviers coudés,
aluminium, noir : 22 5.0
Barre d'accouplement, aluminium,
noire : 22 5.0
Support du servo, aluminium, noir :
22 5.0
Rondelle d'aile en carbone (2) : 22
5.0
Plaque de montage électronique en
carbone : 22 5.0
Essieu arrière VHA, Buggy (2) : 22 5.0
Ensemble de reconstruction VHA CVA
(2) : 22 5.0
Corps antichoc, 36,5 mm, G3 3.5 (1)
Corps antichoc, 42 mm, G3 3.5 (1)
Bras d'amortisseur, 42,7 mm, G3
3.5 (1)
Bras d'amortisseur, 48,7 mm, G3
3.5 (1)
Inserts avant en aluminium 2/4 mm
Italiano
Vite, coppa ammortizzatore G3 (8)
Viti a testa piatta, M2.5 x 4mm (10)
Grano, M3 x 20mm (10)
Viti testa a brugola, M2.5 x 10mm
(10)
Viti testa tonda, M3 x 4mm (10)
Perno sferico, 4.8 x 12mm (4)
Dado di bloccaggio fl angiato allum.
nero, M4 x 0,7 x 7 mm (4)
Perno sferico montaggio basso 4,8 x
5 mm (4)
5 x 8 x 2.5mm cuscinetti (2)
Esagono posteriore, larghezza
standard, alluminio
Sfere diff. al carburo di tungsteno,
3/32 (14)
Grasso silicone diff., 8cc: 22
Anelli trasmissione (2)
Set trascinatore
Ala anteriore bassa trasparente con
montante (2)
Set biella a campana, alluminio, nero:
22 5.0
Tirante longitudinale, alluminio, nero:
22 5.0
Montaggio servo, alluminio, nero:
22 5.0
Rondella ala carbonio (2): 22 5.0
Piastra di montaggio elettronica
carbonio: 22 5.0
Assale posteriore VHA, buggy (2):
22 5.0
Set rigenerazione VHA CVA (2): 22
5.0
Scocca ammortizzatore, 36,5 mm,
G3 3.5 (1)
Scocca ammortizzatore, 42 mm, G3
3.5 (1)
Albero ammortizzatore, 42,7 mm, G3
3.5 (1)
Albero ammortizzatore, 48,7 mm, G3
3.5 (1)
Inserti ant. allum. anteriore 2/4 mm
