Please note: for overhead rigging in public or industrial areas, a series of safety instructions have to be
followed that this manual can only give in part. The operator must therefore inform himself on the current
safety instructions and consider them.
The manufacturer cannot be made liable for damages caused by incorrect installations or insufficient safety
precautions!
Install the safety bond by inserting the quick link in the safety bond hole. Pull the safety bond over the
trussing system etc. Insert the end in the quick link and tighten the fixation screw.
The maximum drop distance must never exceed 20 cm.
A safety bond which already held the strain of a crash or which is defective must not be used again.
OPERATION
Battery Operation
The device features a rechargeable lithium battery for cable-free operation. Prior to initial use, completely
charge the battery.
1
Connect the charger to the power input at the device and the mains plug to a mains outlet (100-240 V
AC, 50/60 Hz). The indicator light on the charger turns red while the battery is charging, then it turns
green when the battery is done charging. The battery can be charged before, during or after operation.
To charge the battery with the LED off, leave the power switch in the off position.
2
The device features a protective circuit for charging which prevents overload of the rechargeable battery.
However, disconnect the device from the mains after charging. Otherwise there will be a low current
consumption even if the device is switched off.
3
The device will heat up during charging; this is normal.
4
To prevent damage to the battery by deep discharge, recharge a battery completely discharged as soon
as possible. Do not store the unit with the battery completely discharged and regularly recharge the
battery in case of long storage.
Maximum battery run time
5 1/2 hours
EUROLITE IR-7 remote control
The IR remote control allows convenient on/off and brightness control of the device. When actuating a
button, always hold the remote control in the direction of the sensor. There must be visual connection
between the
LED on/off
Brightness +
Recharge time
6 hours
remote control and the sensor.
max. Brightness
Brightness –
15/16
00089225.DOC, Version 1.0
