The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage.
Prior to the first operation remove the foil from the battery support on the rear side of the remote control.
Otherwise operation of the remote control is not possible.
Replacing the Battery
If the range of the remote control decreases (10 meters as a maximum), replace the
battery. For this purpose, on the rear side of the remote control press the small bar with the
groove to the right and at the same time remove the battery support. For operation, one 3 V
button cell type CR 2025 is required. When inserting, pay attention that the positive pole of the button cell
shows upwards in the support.
Danger of explosion when battery is replaced improperly. Only replace by the same type.
Please dispose of old and used batteries properly. Batteries are hazardous waste and should
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device.
Maintenance and service operations are only to be carried out by authorized dealers.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Battery pack type:
Battery operation:
Recharging time:
Battery remote control:
LED type:
Number of LEDs:
Color temperature:
Outside/image diameter (logo):
Beam angle:
Dimensions (LxWxH):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Min.distance from flammable surfaces:
Min.distance to lighted object:
Please note: Every information is subject to change without prior notice. 22.01.2015 ©
CAUTION!
not be disposed of with regular domestic waste!
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
8.4 V, 1 A via charger (100-240 V AC, 50/60 Hz)
8.4 W
Li-ion 7.4 V, 4400 mAh (32.56 Wh)
5.5 hours
6 hours
CR2025 button cell 3 V
10 W
1
12000 K
26mm/19mm
10° - 23°
180 x 70 x 165 mm
0.9 kg
:
45° C
a
:
50° C
C
0.5 m
0.1 m
16/16
00089225.DOC, Version 1.0
