INSTALLATION
Inserting/Exchanging gobos
If you wish to use other forms and patterns as the standard-gobos, or if gobos are to be exchanged, please
follow the instructions below:
Unscrew the screw and of the gobo holder and remove the gobo holder of the housing.
Remove the fixation-ring with an appropriate tool. Remove the gobo and insert the new gobo. Press the
fixation-ring together and insert it in front of the gobo.
When installing gobos, please make sure that the mirror-inverted side points away from the LED.
Replace the gobo holder and tighten the screw.
Rigging
The device easily attaches to metal surfaces with its magnetic base (remove clip for this) or to drop ceilings
with its scissor clip. Adjust the desired pan and tilt angles.
Hanging installation
The installation of the device has to be built and constructed in a way that it can hold 5 times the weight for 1
hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall down
if the main attachment fails.
The device has to be installed out of the reach of people.
The device must never be fixed swinging freely in the room.
Caution: Devices may cause severe injuries when crashing down! If you have doubts concerning the safety
of a possible installation, do NOT install the device!
Before rigging make sure that the installation area can hold a minimum point load of 5 times the device's
weight.
When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
For overhead use (mounting height >100 cm), always install an appropriate safety bond.
You must only use safety bonds and quick links complying with DIN 56927, shackles complying with DIN EN
1677-1 and BGV C1 carbines. The safety bonds, quick links, shackles and the carbines must be sufficiently
dimensioned and used correctly in accordance with the latest industrial safety regulations (e. g. BGV C1,
BGI 810-3).
DANGER!
Install the gobos with the device switched off only.
Unplug from mains before!
DANGER OF FIRE!
14/16
00089225.DOC, Version 1.0
