The earth has to be connected!
If the device will be directly connected with the local power supply network, a disconnection switch with a
minimum opening of 3 mm at every pole has to be included in the permanent electrical installation.
The device must only be connected with an electric installation carried out in compliance with the IEC-
standards. The electric installation must be equipped with a Residual Current Device (RCD) with a maximum
fault current of 30 mA.

OPERATION

After you connected the spot to the mains, you can control the spots via your lighting controller.

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no servicable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
Should you have further questions, please contact your dealer.

TECHNICAL SPECIFICATIONS

Power supply:
Power consumption:
Dimensions (LxWxH):
Weight:
Maximum ambient temperature T
Maximum housing temperature T
Minimum distance:
Number of LEDs:
Optional accessories:
EUROLITE TH-90 theatre-hook for 50mm pipe
Safety-rope 40cm x 3mm up to 10kg
Safety-rope 90cm x 3mm up to 10kg
Safety-rope 140cm x 3mm up to 10kg
Please note: Every information is subject to change without prior notice. 07.04.2006 ©
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
:
B
230 V AC, 50 Hz ~
20 W
220 x 210 x 220 mm
1.5 kg
45° C
60° C
0,10 m
151
No.
58000720
58010120
58010130
58010135
16/29 51913614_V_1_0.DOC
