OPERATION
Three seconds after you connected the LED IP LP-7 Logo Projector to the mains, the device starts running.
Via the rotary-control, you can adjust various rotation speeds of the gobo or static gobo (see capture
overview).
When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
CLEANING AND MAINTENANCE
We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no serviceable parts inside the device. Maintenance and service operations are only to be carried
out by authorized dealers.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by authorized dealers only in
order to avoid hazards.
Should you have further questions, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
Protection grade:
LED type:
Number of LEDs:
Color temperature:
Sharpness-range:
Rotation-speed:
Rotation:
Outside/image diameter (logo):
Beam angle:
Dimensions (LxWxH):
Maximum ambient temperature T
Maximum housing temperature T
Min. distance from flammable surfaces:
Min. distance to lighted object:
Weight:
DANGER OF FIRE!
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
:
a
(steady state):
C
12 V DC, 1 A
via supplied power unit (100-240 V AC, 50/60 Hz)
<10 W
IP 54
SMD 7070, 7 W
1
6500 K
1 - 15 m
max. 2 rotations per minute
360°
35mm/26mm
19°
177 x 136 x 171 mm
45° C
80° C
0.5 m
0.1 m
0.7 kg
14/16
00108624, Version 1.0
