Inserting batteries

Open the battery compartment and
insert batteries (2 x typ AAA)
according to the symbols.
Be sure to pay attention
to polarity.
a
1.
2.
Switch on, measure and switch off:
device on
1x
!
After switching on, the device starts with continuous
measurement.
Change measurement point (reference):
rear (device on)
LaserRange-Master T2
DISPLAY:
b
Measurement point (reference)
a
rear / front / thread
c
Continuous measurement /
b
Length measurement
d
Intermediate values
c
Measurement values /
d
Measurement results
Unit m / ft / inch / _' _"
KEYPAD:
1.
Measure
ON / OFF
2.
Measurement point (reference)
rear / front / thread
1. + 2.
Unit m / ft / inch / _' _"
measure
2 sec
1x
1x
2 sec
front
2x
1 sec
device off
2 sec
1x
thread
3x
1 sec
09
EN
