6
Power supply
1. Shut down the automatic circuit
breaker. Make sure that is shut off
in all poles. Put the power switch
on the lower side of the fan in the
OFF position (in case of vertical
fan's orientation).
7
Power connection
1. Remove the screw and open the
terminal compartment.
2. Loosen the screws of the strain
relief clamp.
3. Push the cable through the cable
entry hole and slide it through the
loosened strain relief clamp and
the cable gland.
4. Connect the L, N and the earth-
ing cable to the terminal.Tight-
en the screws of the strain relief
clamp.
5. Set the cover of the power termi-
nal in place and tighten its screw.
6. The I FAN Move has LI terminal
for connection to a lamp up to
200 W/230 V or 100 W/120V. For
different connection possibilities,
please refer to the wiring dia-
grams on the following pages.
8
Before maintenance
Disconnect the fan from
power mains prior to any
operations on the device.
Switch off the device and remove
the front cover.
9
Removing the impeller
Disconnect the connection (a) and
gently pull out the impeller for
cleaning.
10
Removing the grille
Remove the grille from the front
cover by pressing the latches slight-
ly and pushing the grille forward.
When reinstalling make sure the ar-
row on the grille points towards the
mark (arrow) on the inside of the
front cover.
11
Cleaning
To clean the fan use a soft cloth
slightly moistened in a water-soap
solution or a dry brush.
