90° Installation
5 cm channel
Other types of installation
End cap

Connection to the mains

Connect the last tube to the power cord, making sure that the poles are correct. The maximum load of the
power cord is 900 W. Connect the power cord to the mains. Make sure that the outlet is in a dry area. After
connecting the lighting chain to the mains, the LEDs start burning.
Note: The lighting chain may not be connected to dimming packs! After the installation, the power supply
cord, the plug, and the connector must be free of any tractive forces and rotary forces. The lighting chain
must never be covered with any object.
L-connector
The last tube has to be terminated with an end cap. Please
make sure that you stick the end cap on the tube.
15/16
180° Installation
5 cm channel
00046328.DOC, Version 1.1
