Octagon SF 1008C SE+ HD INTELLIGENCE Bedienungsanleitung Seite 99

Audio / Video & Data IN/OUT
TV SCART
HDMI
Optic
Ethernet
RS-232C
Front Panel
Display
Buttons
Power Supply
Input Voltage
Type
Power Consumption
Standby Power
Protection
Physical Specification
Size (W x H x D)
Weight (Net)
Operating Temp.
Storage Temp.
RGB, Y/C, CVBS Video, Audio L, R Output
RCA CVBS Video Output, Audio L, R Output
Video & Audio Output
AC3 Dolby Digital (SPDIF)
USB USB 2.0 Host Support (1 Front & 2 Rear)
RJ45 connector, 10/100M Base
9 pin D-SUB (Male) type, Transfer rate 115Kbps
Slot 1 USB 2.0 Host Slot
2 Common Interface PCMCIA slots
1 Smart Card Slot
7-Segment (4 Digit)
3 Buttons(Standby, CH UP/DN)
AC 100 ~ 250V, 50/60Hz
SMPS
Max. 30W
Max. 1W
Separate Internal Fuse & Lighting protection
260mm X 43mm X 180mm
1.1 Kg
0°C ~ +45°C
-10°C ~ +70°C
47
