INSTALLATION INSTRUCTIONS 3
3. The rear of the shower toilet is aligned with the sound insulation mat and the water outlet pipe is inserted into the
shower toilet from the rear. The flush opening and the waste water connection of the shower toilet are directed
towards the corresponding position of the sound insulation mat. Move the toilet slowly towards the wall in the
direction of the arrow until it is close to the wall.
24
BERNSTEIN SHOWER-WC T640 Pro
Sewage hole
Toilet mat
Flushing opening
Fixing screw (the screw exposes approx. 60 mm from the wall)
Water outlet pipe
Toilet mat
Water outlet pipe
