REQUIRED TOOLS
INSTALLATION INSTRUCTIONS 1
1. Before installing the shower toilet, you should ensure that the bathroom is protected by a residual current circuit
breaker. It is also recommended that power connections are at least 30 cm from the centre of the toilet. As the
model complies with protection class IPX4, other sanitary installations such as the washbasin or bathtub should
be at least 60 cm away from the power connection. Check the alignment of your pre-wall installation as shown in
the drawing and then arrange the water outlet pipe in front of the toilet. then arrange the water outlet pipe in front
of the wall.
Water inlet pipe
Water outlet pipe
Flushing opening
Installation openings
Sewage connection
22
BERNSTEIN SHOWER-WC T640 Pro
10 mm
13 mm
Adjustable for raising or lowering
Level ground
