BEDIENUNGSANLEITUNG / USER MANUAL Deutsch / English Box-Kamera Box camera Modelle / Models: VTC-8100P VTC-8112P VTC-8200P VTC-8212P VTC-8300WDP VTC-8312WDP Das abgebildete Objektiv ist nicht im Lieferumfang enthalten. The lens shown in the picture above is not included in the delivery.
Seite 2
Sanyo Video Vertrieb AG. Der Nachdruck – auch auszugsweise – ist verboten. Irrtum und technische Änderungen vorbehalten. SANTEC ist ein eingetragenes Warenzeichen der Sanyo Video Vertrieb AG. Übrige evtl. genannte Firmen- und Produktnamen sind Warenzeichen oder eingetragene Warenzeichen bzw. Marken der jeweiligen Inhaber.
Seite 3
Please follow all instructions and observe the warnings contained in this manual. Please contact your local dealer or use the SANTEC Service Hotline if you have any questions or if you wish to claim for a service or warranty.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP DEUTSCH Inhaltsverzeichnis Allgemeine Vorsichtsmaßnahmen Allgemeine Sicherheitshinweise Lieferumfang Installation Halter und Kamerabefestigung Stromversorgung und Monitor-Impedanz Einstellungen 2.3.1 OSD 2.3.2 IR-Sperrfilter 2.3.3 Kamera-Selbsttest 2.3.4 Auflagemaß 2.3.5 Licht-Einstellung für beleuchtete Seitenstreifen und Logo mittels OSD 2.3.6 Einstellung des G-Sensor OSD...
Seite 5
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP ENGLISH Table of contents Safety precautions Safety instructions Items included in the delivery Installation 2.1 Bracket and camera installation 2.2 Power supply and monitor impedance 2.3 Adjustments...
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Allgemeine Vorsichtsmaßnahmen Vorsicht VORSICHT LEBENSGEFAHR NICHT ÖFFNEN VORSICHT: SETZEN SIE SICH NICHT DER GEFAHR EINES ELEKTRISCHEN SCHLAGES AUS UND ÖFFNEN SIE NICHT DIE GEHÄUSEABDECKUNG ODER DIE GERÄTERÜCKSEITE.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Allgemeine Sicherheitshinweise Vor Inbetriebnahme des Gerätes sollte dieses Handbuch sorgfältig gelesen und als Nachschlagewerk verwahrt werden. Vor jeder Reinigung muss das Gerät ausgeschaltet und von der Betriebsspannung getrennt werden.
Seite 8
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Bei Betriebsstörungen oder einem vollständigen Betriebsausfall schalten Sie das Gerät aus und trennen es von der Versorgungsspannung. Versuchen Sie niemals, selbst Wartungs- oder Reparaturarbeiten bei geöffnetem Gehäuse durchzuführen, da Sie sich gefährlichen Spannungen aussetzen.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 2.3. Einstellungen Alle Einstellungen sind von außen möglich. Es nicht notwendig, die Kamera zu öffnen! 2.3.1 OSD Die Kameraeinstellungen erfolgen komplett über ein Bildschirm-Menü (OSD). Auf der Rückseite der Kamera finden Sie einen kleinen Joystick.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 2.3.4 Auflagemaßeinstellung Die Kamera hat einen „CS-Mount“ Objektivanschluss. Je nach verwendetem Objektiv kann es notwendig sein, den mitgelieferten C-Mount Adapter zu verwenden. Sollte sich trotzdem am Objektiv keine Bildschärfe (Fokus) einstellen lassen, so haben Sie die Möglichkeit, mit dem Einstellring das Auflagemaß...
Seite 12
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Drücken Sie ca. 5 Sekunden auf den kleinen Joystick auf der Rückseite der Kamera und das OSD zur Einstellung des LED-Lichts wird im Videobild angezeigt: OSD für VTC-8100P und VTC-8112P:...
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 2.3.6 Einstellung des G-Sensor OSD (nur bei VTC-8200P, VTC-8212P, VTC-8300WDP und VTC-8312WDP) Diese Kamera ist mit einem G-Sensor ausgestattet, der zwei Funktionen ermöglicht: a. eine „Detektion“, ob die Kamera nach der Installation verdreht wurde, was somit auch einen Sabotageschutz bietet.
Seite 14
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP a. G-Sensor-Funktion „Detektion“ Eine Empfindlichkeitseinstellung zwischen 2 und 9 aktiviert die G-Sensor Detektion. Bewegung: Reaktion auf Bewegung der Kamera durch leichtes Verdrehen (horizontal oder vertikal) ...
Seite 15
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Hinweise: Die Einstellung der Alarmdauer ist für Bewegung bzw. Schlag getrennt einstellbar. Ein Alarm wird durch die Anzeige im Videobild, den geschalteten Ausgangskontakt und durch eine pink-farbene LED auf der Vorderseite der Kamera angezeigt.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 4. Anschlüsse Kamera-Rückseite mit Anschluss-Interface: VTC-8100P: Day/Night In Betriebsspannungseingang (Schaltkontakt- (90-240 V AC) Eingang) Day/Night Out (Schaltkontakt- Joystick Ausgang/Schließer) BNC-Buchse (Videosignal) Motion Out (Schaltkontakt- Ausgang/Schließer)
Seite 18
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP VTC-8200P und VTC-8300WDP: Day/Night In (Schaltkontakt- Eingang) Betriebsspannungseingang (90-240 V AC) Day/Night Out (Schaltkontakt- Ausgang/Schließer) Joystick Motion Out (Schaltkontakt- BNC-Buchse Ausgang/Schließer) (Videosignal) G-Sensor Out RS-485 (A/B)
Seite 19
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Auf der Kamerarückseite befinden sich folgende Elemente: Joystick: zum Aufrufen des Kamera Setup OSD (kurzer Druck auf den Joystick) zum Aufrufen des LED bzw. G-Sensor OSD (5 Sekunden Druck auf den Joystick)
Seite 20
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP RS-485 (A / B ) (nur bei VTC-8200P, VTC-8212P, VTC-8300WDP und VTC-8312WDP):: Die Kamera kann über eine serielle Verbindung (RS-485) eingestellt werden. Als Übertragungsprotokoll werden die Befehl nach Pelco D verwendet. So erfolgt der Aufruf des Kamera OSD mit dem Befehl für SET-PRESET 95.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 5. Einstellung der Kamera über das OSD (Bildschirm-Menü) Die Kameraeinstellungen erfolgen komplett über ein Bildschirm-Menü (OSD). Auf der Kamera-Rückseite finden Sie einen Mini-Joystick. Drücken Sie oben auf diesen Joystick und es öffnet sich ein Menü...
Seite 22
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Objektiv (Lens Option): Die Objektivsteuerung ist auf DC voreingestellt. Durch Druck auf den Joystick öffnet sich ein Menü und Sie können die Bildhelligkeit nachregeln (0–70). Nochmaliger Druck auf den Joystick speichert den Wert ab.
Seite 23
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Gegenlichtkontrolle (Backlight): BLC: Wenn das Objekt einem starken Hintergrundlicht ausgesetzt ist, ist es möglich, durch die „Backlight“ Funktion ein scharfes Bild des Objekts und des Hintergrunds zu erreichen.
Seite 24
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Spezial (Special): Titel Kam Ein Kameratitel/-name oder eine Kameranummer kann auf dem Bildschirm eingeblendet werden (max. 15 Zeichen). Wählen Sie durch Bewegung des Joysticks nach rechts/links/oben/unten den gewünschten Buchstaben/Zahl aus und bestätigen Sie Ihre Auswahl durch Druck auf den Joystick.
Seite 25
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Bewegungserkennung (Motion Detection) EIN/AUS: Mit dieser Kamera können Sie Bewegungen in acht verschiedenen Überwachungsbereichen verfolgen. Der Hinweis „Motion Detection“ wird im Videobild eingeblendet und der Schaltkontakt wird geschlossen, wenn eine Bewegung erkannt wurde.
Seite 26
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Privatzonen (Privacy) EIN/AUS: Privatzonen, hier erfolgt keine Anzeige des Bildes. o Bereichsauswahl (Area Sel): Bis zu acht Privatzonen können bestimmt werden. o Modus Bereich (Area Mode): Aktivierung oder Deaktivierung des gewählten Bereichs.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Safety precautions Caution Description of symbols Danger: This symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to a person.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Safety instructions Before operating the appliance, please read this manual carefully and retain it for further reference. Before cleaning the appliance, it has to be switched off and unplugged from the power outlet.
Seite 34
Please respect local regulations on waste disposal. About this user manual This manual aims at assisting the user on how to operate camera VTC-8100P, VTC-8112P, VTC-8200P, VTC-8212P, VTC-8300WDP and VTC-8312WDP. This manual is subject to rigid quality control. However, no guarantee can be given that mistakes are not present.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 1. Included items 1 x camera VTC-8100P, VTC-8112P, VTC-8200P, VTC-8212P, VTC-8300WDP or VTC-8312WDP 1 x C-mount adapter 1 x Allen wrench to adjust the back focal distance...
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 2.4. Adjustments All adjustments are accessible from the outside, thus there is no need to open the camera housing. 2.4.1 OSD The camera adjustments are done by an OSD (on-screen-display) menu. On the backside of the camera you will find a mini-joystick.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 2.4.4 Flange back adjustment The camera has a CS-mount lens thread. Depending on the used lens it may be necessary to use the C-mount adapter (which is included in this delivery).
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP On the backside of the camera you will find a mini-joystick. Press it down for approx. 5 sec. The OSD to adjust the LED lights pops up in the video picture:...
Seite 39
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 2.4.6 G-sensor OSD adjustment (only for VTC-8200P, VTC-8212P, VTC-8300WDP and VTC-8312WDP) This camera is equipped with a G-sensor which has two basic functions: a. a „detection“ function which serves as tool to indicate whether the camera has been moved after its installation;...
Seite 40
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP a. G-sensor function „detection“ The detection function of the G-sensor is activated by setting the sensitivity from 2-9. Creep: Reaction of camera movement towards slight position changes (horizontally or vertically).
Seite 41
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Notes: The alarm duration can be set separately for motion and impact. If an alarm is triggered, it will be indicated by a display in the video picture, the set output contact and by the pink LED at the camera front.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 3. Camera overview Picture 1: Sideview illuminated strip thread for camera mounting (can be switched off) lens mount CS-mount connection for thread for camera mounting...
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP On the backside of the camera the following is located: Joystick: to open the camera setup OSD (press briefly onto the joystick) to open the LED lights OSD and the G-sensor OSD (press for approx. 5 sec onto the...
Seite 46
UTP A / UTP B (only for VTC-8200P, VTC-8212P, VTC-8300WDP and VTC-8312WDP): Besides a BNC video output, this camera has a UTP output (twisted pair). An active twisted pair transmitter is built-in into the camera. It is recommended to use SANTEC VEZ-1000 as twisted pair receiver.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 5. Camera adjustment via OSD menu All camera adjustments are done via an OSD menu. On the camera there is a mini-joystick. Press onto the joystick and a menu pops up in the video picture. You can now move the joystick left/right/up/down in order to get to the desired menu item.
Seite 48
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Lens Option: The lens control is pre-set to DC. By pressing the joystick, a menu pops up. You can then adjust the brightness (0–70).
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Backlight: BLC: Backlight compensation. If the lens is exposed to strong backlight, you can activate the „backlight“ function in order to achieve a clear picture of both the object itself and the background.
Seite 50
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Special: Title cam A camera title/name can be displayed on the screen (max. 15 characters). Move the joystick left/right/up/down to select the desired letter/number. Confirm your choice by pressing the joystick.
Seite 51
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Motion Detection: You can detect motions in eight different areas. The note „Motion Detection“ is displayed in the video picture and the switch contact is closed if the event occurs.
Seite 52
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Privacy: Privacy zones are not displayed on the screen. o Area Sel: Up to eight privacy zones can be selected. o Area Mode: Activation or deactivation of the selected area.
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP 6. Special features General: day/night colour camera with mechanical IR cut filter multi-language OSD menu (via joystick) digital image stabiliser (DIS) ...
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Technical specifications: Cameras VTC-8100P and VTC-8112P Camera VTC-8100P VTC-8112P Camera type day/night colour camera in box housing Video norm Sensor 1/3“ Sony CCD chip Horizontal resolution...
Seite 55
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Technical specifications: Cameras VTC 8200P and VTC-8212P Camera VTC-8200P VTC-8212P Camera type day/night colour camera in box housing Video norm Sensor 1/3“ Sony CCD chip...
Seite 56
Bedienungsanleitung / User manual VTC-8100P / VTC-8112P / VTC-8200P / VTC-8212P / VTC-8300WDP / VTC-8312WDP Technical specifications: Cameras VTC 8300WDP and VTC-8312WDP Camera VTC-8300WDP VTC-8312WDP Camera type day/night colour camera in box housing Video norm Sensor 1/3“ Sony CCD chip...
