Installation
the speakers must not be lower than 2 Ohms.
10. Connecting the remote output
This output (Rem Out) is used to supply remote
signals to the external amplifier/s. Always use
this remote output signal to turn on the ampli-
fiers in order to avoid on/off switching noises.
Examples for adjusting the input sensitivity:
Source
4-channel OEM radio
Up to 25 Watts RMS power each channel
OEM radio with additional 4-channel amplifier
Up to 100 Watts RMS power each channel
OEM radio with additional 6-channel amplifier
Up to 100 Watts RMS power each channel
4-channel aftermarket radio without
pre-amplifier outputs
Up to 25 Watts RMS power each channel
4-channel aftermarket radio with
pre-amplifier outputs
2 Volts pre-amplifier output voltage
4-channel aftermarket radio with
pre-amplifier outputs
4 Volts pre-amplifier output voltage
5/6-channel aftermarket radio with
pre-amplifier outputs
8 Volts pre-amplifier output voltage
22
Which input? Position
Jumper A
Highlevel A-D A1
Highlevel A-D A2
Highlevel A-F A2
Highlevel A-D A1
Lowlevel / A1
RCA A-D
Lowlevel / A1
RCA A-D
Lowlevel / A2
RCA A-F
Position Position of
Jumper B control 9
Optional Max. CCW
position
Optional Max. CCW
position
B2 Max. CCW
position
Optional Max. CCW
position
Optional Max. CW
position
Optional Max. CCW
position
B2 Max. CCW
position
