DESCRIPTION OF THE DEVICE
Features
LED DMX mirror ball effect
Milky half ball with 34 clear lenses • Equipped with 5 x 3 W LEDs • 20 rotations per minute • Operable in
stand-alone mode or with DMX interface • DMX-512 control possible via any commercial DMX-controller
(occupies 8 channels) • DMX-starting address, stand alone operation with Master-/Slave-function and speed
are adjustable via dip switches • Sound-control via built-in microphone • Microphone-sensitivity adjustable via
rotary-control • Functions: Static colors; stepless RGBAW color blend; internal program; Dimmer, Strobe
settings rotation direction and speed adjustable via DMX; Master/Slave • Hanging or standing installation
possible • Mounting bracket for installation on a trussing system included • Ready for connection via power
cord with safety plug
Overview
INSTALLATION
Rigging
When installing the device, make sure there is no highly-inflammable
material (decoration articles, etc.) within a distance of min. 0.5 m.
The device can be installed on the ground or on the wall or ceiling.
1
2
3
4
5
6
DANGER OF FIRE!
1.
DMX IN
2.
Fuse
3.
DMX OUT
4.
Microphone
5.
Power supply
6.
Rotary control
7.
Attachment eyelet
7
18/25
00063044.DOC, Version 1.1
