Energetics XT 910 Handbuch Seite 7

Part Description
1 Main frame
2 Front stabilizer
3 Sliding beam
4 Oval cap
5L Left foot cap
5R Right foot cap
6 Curved washer D22*D8.5*1.5T
7 Spring washer D15.4*D8.2*2T
8 Flat washer D21*D8.5*1.5T
9 Allen bolt M8*1.25*20L
9a Square neck bolt M8*1.25*90L
9b Square neck bolt M8*1.25*75L
9c Allen bolt M8*1.25*15L
10 Handlebar post
11L Supporting tube for left pedal
11R Supporting tube for right pedal
12L Supporting tube for left movable
handlebar
12R Supporting tube for right movable
handlebar
13 Bearing #99502ZZ
14 Flat washer D16*D8.5*1.2T
15 Mushroom cap D1 1/4''*29L
16 Idle wheel
17 Nylon nut M10*1.5*10T
18 Connecting tube
19 Rear stabilizer
20 Domed nut M8*1.25*15L
21 Pedal
22 Adjustable round wheel
23L Upper cover (left)
23R Upper cover (right)
24 Anti-loose nut M10*1.25*7T
25 Controller
26 C-ring D22.5*D18.5*1.2T
27 Fixing plate
28 Adjustable round wheel
29 Upper computer cable
30 Lower computer cable
31 Round cap
32L Bracket for left pedal
32R Bracket for right pedal
33 Crank
34 Nylon nut M8*1.25*8T
Qty Part Description
1 51 Spring washer D10.5*D6.1*1.3T
1 52L Left movable handlebar
2 52R Right movable handlebar
2 53 Foam (HDR) D30*3T*500L
1 54 Foam (HDR) D30*4T*125L
1 55 Mushroom cap D1 1/4"*45L
16 56 Spring D2.6*D15*82L
28 57 Bolt M6*1.0*15L
12 58 C-ring D21.5*D17.5*1.2T
20 59 Waved washer D26*D19.5*0.3T
2 60 Flat washer D22*D10*2T
2 61 Crank axle
4 62 Belt wheel
1 63 Screw ST4*1.41*15L
1 64 Computer VM6618
1 65 Handle pulse
1 Handle pulse cable 600L
1 66 Allen bolt M8*1.25*50L
4 67 Left computer bracket
8 68 Right computer bracket
2 69 Joint
1 70 Fixing plate for idle wheel
2 71 Waved washer D21*D16*03T
1 72 Bushing
1 73 Bolt M6*1*15L
4 74A Left cover for universal joint
2 74B Right cover for universal joint
2 75 C-clip
2 76 Cone shaped washer
2 77 Flat washer D26*D21*1.5T
2 78 Bearing 608ZZ
1 79 Cover for crank
2 80L Enforcing plate of left pedal
2 80R Enforcing plate of right pedal
2 81 Handlebar
1 82 Nylon nut M8*1.25*8T
1 83 Bushing D17.9*10L
2 84 Cable plug
1 85 Nylon nut M10*1.5*10T
1 86 Fixing plate for the post
2 87 Fixing plate for computer
1 88 Nylon nut M6*1.0*6T
7
Qty
4
1
1
2
2
2
1
4
6
6
1
1
1
15
1
2
2
2
1
1
2
1
2
14
4
2
2
2
4
1
4
2
1
1
1
3
2
2
1
1
1
4
