TECHNICAL SPECIFICATIONS
Power supply:
Power consumption:
IP classification:
Protection class:
Power connection:
Power output:
Fuse:
LED:
Flash rate:
DMX channels:
DMX input:
DMX output:
Cooling:
Control:
Beam angle (1/2 peak):
Housing color:
Display type:
Dimensions:
Weight:
All information is subject to change without prior notice. © 08.11.2021
Accessories
EUROLITE TPC-10 Coupler, silver
EUROLITE TPC-10 Coupler, black
EUROLITE Safety Bond UNV-5 3x600mm up to 5kg silver
EUROLITE Safety Bond UNV-5S 3x600mm up to 5kg black
EUROLITE DMX cable XLR 3pin 3m black
PSSO DMX cable XLR 3pin 3m black Neutrik
OMNITRONIC IEC Extension 3x1.0 3m black
Eurolite is a brand of Steinigke Showtechnic GmbH · Andreas-Bauer-Str. 5 · 97297 Waldbüttelbrunn Germany
D00135837.docx Version 1.0 Publ. 08/11/2021
100-240 V AC, 50/60 Hz
15 W
IP20
Class I
Mains input IEC connector (M) mounting version
Power supply cord with safety plug (provided)
IEC connector (F) mounting version
T 0,5 A Fuse replaceable
72 x SMD 5050 3in1 TCL RGB (homogenous color
mix)
0 - 20 Hz
3; 5; 6; 12-1; 12-2
3-pin XLR (M) mounting version
3-pin XLR (F) mounting version
Passive convection
Stand-alone; DMX; Master/slave function; Sound to
light via Microphone
120°
Black
4 digits 7-segment LED display
Length: 56,5 cm
Depth: 7,0 cm
Height: 9,0 cm
750 g
No. 59006856
No. 59006858
No. 58010372
No. 58010373
No. 3022785H
No. 30227810
No. 30235201
28/28
00135837, Version 1.0
