5-channel mode
Channel
1
2
3
4
5
6-channel mode
Channel
1
2
3
4
5
6
12-1-channel mode
Channel
1
2
3
4
5
6
7
8
9
10
11
12
12-2-channel mode
Channel Value
1 000 – 255
2
000 – 255
3 000 – 255
4 000 – 255
5 000 – 255
6 000 – 255
7 000 – 255
8 000 – 255
9 000 – 255
10 000 – 255
11 000 – 255
12
000 – 255
Value Function
000 – 255 Red 0-100%
000 – 255 Green 0-100%
000 – 255 Blue 0-100%
000 – 255 Master dimmer 0-100%
000 – 000 No function
001 – 005 Sound-controlled mode (7 colors)
006 – 010 No function
011 – 255 Strobe effect with increasing speed 0-100%
Value Function
000 – 255 Master dimmer 0-100%
000 – 255 Strobe with increasing speed 0-100%
000 – 255 Red 0-100%
000 – 255 Green 0-100%
000 – 255 Blue 0-100%
000 – 015 No function
016 – 255 Automatic program with increasing speed (3 colors)
Value Function
000 – 255 Master dimmer 0-100% 1+2
000 – 255 Strobe effect with increasing speed 0-100%
000 – 255 Red 0-100% 1+2
000 – 255 Green 0-100% 1+2
000 – 255 Blue 0-100% 1+2
000 – 015 No function
016 – 255 Automatic program with increasing speed (3 colors)
000 – 255 Master dimmer 0-100% 3+4
000 – 255 Strobe effect with increasing speed 0-100%
000 – 255 Red 0-100% 3+4
000 – 255 Green 0-100% 3+4
000 – 255 Blue 0-100% 3+4
000 – 015 No function
016 – 255 Automatic program with increasing speed (3 colors)
Function
Red 0-100%
Green 0-100%
Blue 0-100%
Red 0-100%
Green 0-100%
Blue 0-100%
Red 0-100%
Green 0-100%
Blue 0-100%
Red 0-100%
Green 0-100%
Blue 0-100%
26/28
Segment
1
2
3
4
